Factory Directly Supply Customized Gold Plated Molybdenum Wire China

Factory Directly Supply Customized Gold Plated Molybdenum Wire China

customized gold plated molybdenum wire

factory direct gold plated wire

china gold plated molybdenum wire

원래 장소:

중국

브랜드 이름:

WINNER

인증:

ISO9100

모델 번호:

MW001

문의하기
조회를 요청하다
제품 상세정보
애플리케이션:
반도체 포장, 미세 전자, 의료 기기
패키지:
스풀
부식 저항:
높은
재료:
구리
와이어 직경:
0.001 인치
본드 강도:
높은
길이 미터:
500/1000
제품 유형:
본딩 와이어
코팅 두께:
0.001mm
코팅:
청정:
99.999%
본딩 방법:
초음파
온도 범위:
-40 ° C ~ 200 ° C
표면 마무리:
밝은
전도도:
98%
패키지 크기:
100 미터
강조하다:

customized gold plated molybdenum wire

,

factory direct gold plated wire

,

china gold plated molybdenum wire

지불과 운송 용어
최소 주문 수량
1개
가격
999
포장 세부 사항
롤, 중성 포장 또는 OEM 로고와 함께
배달 시간
5-8 영업일
지불 조건
L/C, 서부 동맹, T/T
공급 능력
달 당 100000의 목록
제품 설명

Gold plated molybdenum wire offers a few advantages versus gold plated tungsten wire. Gold plated molybdenum wire is lighter than tungsten and more ductile. The ductility of molybdenum wire allows it to be woven and used in specific applications like antennae on satellites. Like tungsten wire, gold plated molybdenum wire is used in the medical and electronics industries.


Key Features:

  1. Excellent Electrical Conductivity: The gold coating significantly improves the wire's ability to conduct electricity, making it suitable for high-frequency and high-power electronic components.

  2. Corrosion Resistance: Gold's natural resistance to corrosion ensures that the wire can withstand harsh environments, making it ideal for use in humid or chemically aggressive conditions.

  3. Mechanical Strength: Molybdenum provides excellent tensile strength, enabling the wire to maintain stability in high-temperature applications.

  4. Durability and Stability: The combination of gold and molybdenum makes the wire durable and stable, even under demanding conditions.


Technical Parameters


Items

Data

Chemical analysis (wt%)

Mo ≥ 99.9%, Au : 99.99%

Core wire diameter

25μm/27μm in stock, customized

Coating thickness

0.2 ~ 0.8μm

Max. using temperature

450℃

Anti-temperature shock

bear -196 ~ 250℃ fast cyclical impact


Factory Directly Supply Customized  Gold Plated Molybdenum Wire China 0

Factory Directly Supply Customized  Gold Plated Molybdenum Wire China 1

Factory Directly Supply Customized  Gold Plated Molybdenum Wire China 2

Factory Directly Supply Customized  Gold Plated Molybdenum Wire China 3
